48V High Power Cell With Adaptive Immersion Technology
48V High Power Cell With Adaptive Immersion Technology
48V High Power Cell With Adaptive Immersion Technology

48V High Power Cell With Adaptive Immersion Technology

The 48V Power Max GO delivers 12 kW of Power with a Nominal Capacity of 2.4 kWh....
Vendor: Anodox
Availability: In Stock
€5.148,00
€5.148,00
Subtotal: €5.148,00
Ask An Expert
48V High Power Cell With Adaptive Immersion Technology

48V High Power Cell With Adaptive Immersion Technology

€5.148,00
48V High Power Cell With Adaptive Immersion Technology
48V High Power Cell With Adaptive Immersion Technology
48V High Power Cell With Adaptive Immersion Technology

48V High Power Cell With Adaptive Immersion Technology

€5.148,00
SPECIFICATIONS
SPECIFICATIONS
x
Technical Data 48V Power Cell
Nominal Power (kW) 2.4
Max. Power (kW) 12 to 24
Volumetric Power Density (W/l) 930
Weight (kg) 16
Nominal Energy Capacity (kWh) 2.4
Energy Capacity (90%) Useable (kWh) 2.16
Gravimetric Power Density (W/kg) 750
Volumetric Energy Density (Wh/l) 155
Gravimetric Energy Density (Wh/kg) 150
Dimensions (L x W x H) mm 360 x 335 x 108
Thermal Management Adaptive Immersion Technology
Active Thermal Runaway Suppression
Protection from External Fires
Housing/Certification MuMultiple Composite Options
IP67
ECE R100
Cycles 1000 (@ 5C)
Charge / Discharge C Rates 2C / 10C
PRODUCT DESCRIPTION
PRODUCT DESCRIPTION
x

The 48V Power Max GO delivers 12 kW of Power with a Nominal Capacity of 2.4 kWh. The weight is just 22 kg and the unit has an impressive power density of 930 W/l. The energy density is also solid at 155 Wh/l. The unit has a fast charge capability of 20 min and has the latest Anodox Adaptive Immersion Technology.

Production Start 2024Q4
